ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use

ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use ATEX Certified Portable CL2 Gas Detector with IP68 Waterproof and 0-10ppm Measure Range for Industrial Use
Basisinformatie
Plaats van herkomst: CHINA
Merknaam: SAFEGAS
Certificering: ATEX/EMC/IECEX
Modelnummer: Minimeta
Min. bestelaantal: 1
Prijs: onderhandelbaar
Verpakking Details: karton
Levertijd: 3 werkdagen
Betalingscondities: T/T, Western Union
Levering vermogen: 3000 stuks per maand
Beste prijs Contact nu
Gedetailleerde informatie
Detectieprincipe: Diffusie Afmetingen: 90 mm*60 mm*33 mm (lengte*breedte*dikte)
Gas gedetecteerd: Cl2 Meet bereik: 0-10 ppm 0-50 ppm
Oplossing: 0,01 ppm Gewicht (met clip): 125g
Nauwkeurigheid: ≤ ± 2-5%FS Alarmmodus: Geluids-, licht- en trillingsalarm
Werkluchtdruk: 86 tot en met 106 kPa Reactietijd (T90): 15 tot 30 jaar
Beschermingsklasse: IP66/68 Werktemperatuur: -20 ℃ tot 55 ℃
Beginsel: Elektrochemisch principe Explosieve bestendige certificering: IECEX, ATEX
Werkvochtigheid (niet-condenseren): 0-95%RH Weergave: Gasnaam, batterijvermogen, concentratie-eenheid, gemeten waarde
Voedingsmodus:: 3.6V droge batterij (niet oplaadbaar en vervangbaar) Alarmtype: Laag alarm, hoog alarm, STEL, TWA, laag batterij optioneel kalibreren en bumptest

Productomschrijving

ATEX Certified Portable Single Toxic Gas Detector For Chlorine Industrial Wastewater Plant Use
Product Overview

The MiniMeta Portable CL2 Gas Detector is a high-precision portable gas detector designed for chlorine detection using diffusion detection principle, specifically engineered for industrial safety applications in wastewater treatment plants and similar environments.

This IECEX/ATEX/EMC certified single-gas detector can detect hundreds of user-selected toxic gases. User-friendly and easy to operate, it features replaceable battery and sensor for long-term protection, offering a low-cost, long-term ownership gas monitoring system.

Key Features
  • IP68 water- and dust-resistant case
  • Low power consumption with 2 years standby time - no battery charging or calibration needed
  • Optional single/multi unit docking station for daily bump test and calibration
  • Event and data logging function
  • Self-test function for improved safety through automatic self-testing
  • Small size, lightweight design with back clip for easy carrying
  • 95db@30cm buzzer alarm, 2 high-bright red LED light alarm and vibration alarm
  • Real time value, TWA, STEL, MAX, MIN multiple numerical display
Applications
  • Sewage treatment plant chlorine leak inspection
  • Chemical chlorination workshop toxic gas monitoring
  • Swimming pool disinfection room gas concentration testing
  • Pesticide manufacturing workshop harmful gas early warning
  • Textile bleaching factory workplace safety detection
  • Municipal water disinfection station chlorine leakage alarm
  • And more industrial applications
Portable Chlorine Gas Detector front view showing display and controls Portable Chlorine Gas Detector side view showing compact design Portable Chlorine Gas Detector display close-up showing readings Portable Chlorine Gas Detector back view with carrying clip Portable Chlorine Gas Detector in use scenario at industrial site
Technical Parameters
Parameter Specification
Detect gas CL2 (Chlorine)
Sensor type Electrochemical
Sampling method Diffusion
Measure range 0-10ppm / 0-50ppm
Resolution 0.01ppm
Precision ≤± 3% F.S.
Response Time ≤30s (T90)
Display Gas name, concentration unit, measured value, battery level
Alarm mode Sound, light, vibration alarm
Alarm type Low alarm, high alarm, STEL, TWA, low battery
Operating language Chinese/English
Size 90×60×33mm
Weight 125g
Working Temperature -20ºC to 50ºC
Working Humidity 0-95%RH
Working air pressure 86-106kpa
Company Advantages
  • R&D team experience: over 25 years
  • Company certifications: ISO9001, ISO45001
  • Product certifications: IECEx, ATEX, CE
  • Delivery time: 5-7 days
  • Annual capacity: 80,000 units
  • Professional 7×24 hours customer service
Manufacturer Profile

Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) specializes in the design, production, and sales of gas detection equipment and systems. With 16 years of industry experience, we provide comprehensive solutions for various sectors including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronics, Municipal Engineering, Agriculture, and Household Appliances.

Product Line
Portable Detectors:
  • Minimeta, Micmeta, YT-1200H-S, SKY3000, SKY2000, SKY8000, SKY1000, MAXMETA
Fixed Systems:
  • YT-95H, YT-98H, YT-96H, SG100, SG200
Controllers:
  • YT-1100H, YT-1600H, YT-1800H
Particle Counters:
  • AQD5000, SKY6000-PM, SKY2000-PM
Gas detection product line overview showing various models Industrial gas detection systems installation Gas detection controller units and panels
